Cristal-Flo II Top Mount Sand
Filter - Sta-Rite |
|
Data Sheet
Owners Manual
View Parts Breakdown
|
|
For residential inground or aboveground swimming pools requiring
turnover through 59,000 gallons, at flow rates up to 20 GPM for 8 to 10
hours. Corrosion resistant, one-piece, extra-thick molded polyethylene
tank assures long service life. Top-mounted, corrosion-resistant
multiport selector valve included. Also includes a convenient tank
winterizing drain and continuous air relief system.
 Safe – Internal air relief
hole allows air to automatically escape, preventing high pressure
buildup
|
|
Cristal-Flo II Sand Filter |
|
H2O # |
Manf. # |
Description |
|
1250302 |
145360 |
19.5" Diameter, with
1-1/2" 6 way Valve *** |
|
1250307 |
145361 |
22.5" Diameter, with
1-1/2" 6 way Valve *** |
|
1250309 |
145362 |
24" Diameter, with
1-1/2" 6 way Valve *** |
|
1250311 |
145363 |
26" Diameter, with
1-1/2" 6 way Valve *** |
|
***
Includes the Multiport Valve which is included in the filter carton when
shipped |
Includes Valve
|
|
Specifications: |
|
Model |
Sq. Ft. |
Width |
Height |
Flow Rate
( GPM ) |
Max Pressure
( PSI ) |
Turnover ( in
Gallons ) |
Sand
Req. |
|
8 hr |
10 hr |
12
hr |
|
19.5" |
1.8 |
19-1/2" |
37" |
40 |
35 |
19,200 |
24,000 |
28,800 |
150 lbs. |
|
22.5" |
2.3 |
22-1/2" |
38-1/2" |
60 |
40 |
28,800 |
36,000 |
43,200 |
250 lbs. |
|
24" |
3.15 |
24" |
45-1/2" |
70 |
50 |
33,600 |
42,000 |
50,400 |
300 lbs. |
|
26" |
3.5 |
26" |
47-7/8" |
75 |
50 |
36,000 |
45,000 |
54,000 |
350 lbs. |
|
The Base Foot
Print Measures 19-1/4" |
|
|
Replacement Valves for Cristal-Flo Sand
Filters -
Sta-Rite |
|
|
Replacement
Valves |
|
H2O # |
Manf. # |
Description |
|
1630214 |
262506 |
Newer Cristal-Flo II
1-1/2" top mount multiport valve, clamp style,
Also fits Tagleus 30/40/50/60 series D |
|
1650237 |
14971-TM-22-L |
Older Cristal-Flo 30" Top Mount,
clamp on style
for 30"model, T-300BP-2 filter |
|
|
